MSI MPG Z790 EDGE WIFI DDR4 - Page 32

30
Installing M.2 module into M2_1 slot
1. Press and hold the end button of Screwless M.2 Shield Frozr heatsink.
11
2. Slightly lift up the end part of Screwless M.2 Shield Frozr heatsink and move it
forward to uninstall the heatsink.
22
