MSI MPG Z790I EDGE WIFI - Installing M.2 module into M2_2 slot

30
4. Remove the protective film from the thermal pad under the M.2 Shield Frozr
heatsink.
5. Put the M.2 Shield Frozr heatsink back in place and secure it.
55
55
44
Installing M.2 module into M2_2 slot
1. Loosen the screws of M.2 Shield Frozr heatsink and remove the heatsink.
2. Loosen the screws of M.2 adapter card.
3. Pull out the M.2 adapter card.
11
22
33
22
11
