MSI MPower Z97 - Motherboard Specifications Part 2

Chapter 1
1-5
Getting Started
Audio 󰀲 Realtek
®
ALC1150 Codec
- 󰘰
- Supports S/PDIF output
LAN 󰀲 1x Intel I218-V Gigabit LAN controller
Back Panel
Connectors
󰀲 1x PS/2 keyboard/ mouse port
󰀲 4x USB 2.0 ports
󰀲 1x Clear CMOS button
󰀲 6x USB 3.0 ports
󰀲 1x Optical S/PDIF OUT connector
󰀲 1x HDMI port
󰀲 1x DisplayPort
󰀲 1x LAN (RJ45) port
󰀲 6x audio jacks
Internal
Connectors
󰀲 1x 24-pin ATX main power connector
󰀲 1x 8-pin ATX 12V power connector
󰀲 1x 4-pin ATX 12V power connector
󰀲 1x 6-pin ATX 12V power connector*
󰀲 8x SATA 6Gb/s connectors
󰀲 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
󰀲 1x USB 3.0 connector (supports additional 2 USB 3.0 ports)
󰀲 2x 4-pin CPU fan connectors
󰀲 3x 4-pin system fan connectors
󰀲 1x Clear CMOS jumper
󰀲 1x Front panel audio connector
󰀲 2x System panel connectors
󰀲 1x TPM module connector
󰀲 1x Chassis Intrusion connector
󰀲 9x V-Check connectors
󰀲 1x GO2BIOS button
󰀲 1x Power button
󰀲 1x Reset button
󰀲 2x Base Clock control buttons
󰀲 1x OC Genie button
󰀲 1x Multi-BIOS switch
󰀲 1x OC Genie mode switch
󰀲 1x Slow mode switch
󰀲 1x 2-Digit Debug Code LED
* Provides additional power to PCIe x16 slots
I/O
Controller
󰀲 NUVOTON NCT6792 Controller Chip
Hardware
Monitor
󰀲 CPU/System temperature detection
󰀲 CPU/System fan speed detection
󰀲 CPU/System fan speed control
BIOS
Features
󰀲 󰘱
󰀲 UEFI AMI BIOS
󰀲 ACPI 5.0, PnP 1.0a, SM BIOS 2.7, DMI 2.0
󰀲 Multi-language
