MSI MPower Z97 - Motherboard Specifications Part 1

Chapter 1
1-4
Getting Started
󰘰
CPU
Support
󰀲 Supports 5th and 4th Generation Intel
®
Core™ Processors, and
Intel
®
Pentium
®
and Celeron
®
Processors for the Socket LGA1150
Chipset 󰀲 Intel
®
Z97 Express Chipset
Memory
Support
󰀲 4x DDR3 memory slots supporting up to 32GB
󰀲 Supports DDR3 3200(OC)/3100(OC)/ 3000(OC)/ 2800(OC)/
2666(OC)/ 2600(OC)/ 2400(OC)/ 2200(OC)/ 2133(OC)/ 2000(OC)/

󰀲 Dual channel memory architecture
󰀲 󰘯
󰀲 Supports Intel
®
󰘰
Expansion
Slots
󰀲 3x PCIe 3.0 x16 slots (PCI_E2, PCI_E5, PCI_E7 support x16, x8/x8,
x8/x4/x4 modes)
󰀲 1x PCIe 2.0 x16 slot (PCI_E4, supports x4 speed)*
󰀲 3x PCIe 2.0 x1 slots*
* The PCIe x1 slots (PCI_E1, PCI_E3, PCI_E6) will be unavailable when installing an expan-
sion card in the PCI_E4 slot.
Onboard
Graphics
󰀲 1x HDMI port, supporting a maximum resolution of

󰀲 1x DisplayPort, supporting a maximum resolution of


Multi-GPU
Support
󰀲 Supports 3-Way AMD
®
CrossFire
TM
Technology*
󰀲 Supports 2-Way NVIDIA
®
SLI
TM
Technology
* Supports Windows 7 and Windows 8/ 8.1
Storage 󰀲 Intel Z97 Express Chipset
- 6x SATA 6Gb/s ports (SATA1~6)
- 1x M.2 port*
- M.2 port supports M.2 SATA 6Gb/s module
- M.2 port supports M.2 PCIe module up to 10Gb/s speed**
- M.2 port supports 4.2cm/ 6cm/ 8cm length module
- Supports RAID 0, RAID1, RAID 5 and RAID 10***
- Supports Intel Smart Response Technology, Intel
®
Rapid Start
Technology and Intel Smart Connect Technology****
󰀲 ASMedia ASM1061 Chipset
- 2x SATA 6Gb/s ports (SATA7~8)
* The SATA5 and SATA6 ports will be unavailable when installing a module in the M.2 port.
** Intel RST only supports PCIe M.2 SSD with UEFI ROM, does not support Legacy ROM.
*** M.2 PCIe interface does not support RAID 0, RAID1, RAID 5 and RAID 10.
**** Supports Intel Core processors on Windows 7 and Windows 8/ 8.1
USB 󰀲 Intel Z97 Express Chipset
- 4x USB 3.0 ports (2 ports on the back panel, 2 ports available
through the internal USB connectors*)
- 8x USB 2.0 ports (4 ports on the back panel, 4 ports available
through the internal USB connectors*)
󰀲 ASMedia ASM1074 Chipset
- 4x USB 3.0 ports on the back panel
* Internal JUSB1 connector supports MSI Super Charger.
