MS-6119 ATX BX2 Mainboard
MICRO-STAR INTERNATIONAL COMPANY LTD.
Specification & User’s Guide
Remote Power On/Off Switch: JRMS1/JRMS2
Connect to a 2-pin push button switch. Every time the switch is shorted by pushing it once, the power supply
will change its status from OFF to ON. During ON stage, push once and the system goes to sleep mode:
pushing it more than 4 seconds will change its status from ON to OFF. If you want to change the setup,
you could go to the BIOS Power Management Setup. This is used for ATX type power supply.
JRMS1 / JRMS2
Note: The two switches are provided by the mainboard for your convenience, so you can use any of them.
The two switches have the same feature.
Chassis Intrusion Connector: JP3
This connector is connected to 2-pin connector chassis switch. If the Chassis is open, the switch will be short.
The system will record this status. To clear the warning, you must enter the BIOS settting and clear the status.
JP3
