CHAPTER 4
AMI
®
BIOS USERS GUIDE
4-25
4.8 Hardware Monitor Setup (optional)
The Hardware Monitor Setup is used to set the CPU speed and
monitor the current CPU Temperature, CPU Fan speed, Chassis Fan
Speed, Power fan speed, Vcore, etc.
1. Press <ENTER> on “Hardware Monitor Setup” of the main menu
screen.
AMIBIOS SETUP - HARDWARE MONITOR SETUP
(C) 1999 American Megatrends, Inc. All Rights Reserved
Chassis Intrusion Disabled
CPU Temperature Detected By CPU
CPU Temperature 46
0
C/114
0
F
System Temperature 31
o
C/87
o
F
CPU Fan Speed 4560 RPM
CPU VID 2.00V
Vcore 1.936V
Vtt 2.480V
Vio 3.280V
+5,000V 5.113V
+12,000V 12.045V
-12,000V -11.763V
-5,000V -4.932V
Battery 3.00V
+5V SB 5.60V
Available Options:
Manual
Auto
ESC:Exit :Sel
PgUp/PgDn:Modify
F2/F3:Color
2. Use <Up> and <Down> to choose the item and <PgUp> and
<PgDn> keys to modify the highlighted item.
3. After you have finished with the PCI/Plug and Play Setup, press
<ESC> to go back to the main menu.
