En-3
English
Floppy
- 1 floppy port
- Supports 1 FDD with 360KB, 720KB, 1.2MB, 1.44MB and 2.88MB
RAID
- Supports Intel Martix Storage Technology (AHCI + RAID 0/1/5/10) by
ICH9R
Connectors
Back panel
- 1 PS/2 mouse port
- 1 PS/2 keyboard port
- 6 USB 2.0 ports
- 1 IEEE 1394 port (Optional)
- 1 VGA port
- 1 LAN jack (10/100/1000)
- 2 eSATA ports (Hot plug supported by ICH9R)
- 6 flexible audio jacks
On-Board Pinheaders/ Connectors
- 1 Front Panel Audio pinheader
- 1 CD-In connector
- 1 SPDIF-Out (or SPDIF-In) pinheader
- 1 IEEE 1394 pinheader (Optional)
- 3 USB 2.0 pinheaders
- 1 Chassis Intrusion Switch pinheader
- 1 Serial port pinheader
Slots
- 1 PCI Express x16 slot
- 1 PCI Express x1 slot
- 2 PCI slots
- Support 3.3V/ 5V PCI bus Interface
Form Factor
- Micro-ATX (24.4cm X 24.4cm)
Mounting
- 8 mounting holes
