MSI MS-N0E1 User Manual

110W（MS-N0E1）Disassembly Guide
3、LCD MODULE ASSY
3.4：Remove the camera.
Component P/N Qty
Camera S1F-0001870-B36 1
3.5： Remove the 1 screw (M2*2.5mm). Then
remove the OFN shield.
Attention：the screw driver torque is 0.5-1.0Kgf-cm
Component P/N Qty
Screw E43-1203003-H29 1
3.6：Remove the FFC, and then remove the OFN
board.
Component P/N Qty
OFN Board OS1-N0D1001 1
