110WMS-N0E1Disassembly Guide
3LCD MODULE ASSY
3.1Remove the antenna.
3.2Remove the LVDS cable.
3.3Remove the 4 screws (M2*3mm), after that
remove the shield.
Attentionthe screw driver torque is 1.2-1.5Kgf-cm
Component P/N Qty
Screw E43-1203003-H29 4
Shield
307-0E10111-A89 1
