110W（MS-N0E1）Disassembly Guide
2、MB ASSY
2.22：Remove the 2 screws (M2*3mm), after that
remove the MB.
Attention：the screw driver torque is 1.2-1.5Kgf-cm
Component P/N Qty
Screw E43-1203003-H29 2
2.23: Remove the FFC.
Component P/N Qty
MB 607-N0E11-01S 1
2.24: Remove the 4 screws (M2*3mm), after that
remove the speaker.
Attention：the screw driver torque is 1.2-1.5Kgf-cm
Component P/N Qty
Screw E43-1203003-H29 4
Speaker S78-1310030-SY7 1
