110W（MS-N0E1）Disassembly Guide
3、LCD MODULE ASSY
3.9：Dip the cleaning rod with Alcohol into the gap
between the Touchpad and the Bezel (wait 10
minutes to let the Alcohol infiltrate surrounding areas
of the Bezel).
3.10：Disassemble the touchpad according to
following steps as the picture: from the side1
to side3, and then from side2 to side4.
3.11： Pull the left lower corner of the Bezel to
separate with the touchpad.
To Next Page
