110W（MS-N0E1）Disassembly Guide
3、LCD MODULE ASSY
3.15： Dip the cleaning rod with Alcohol into the
adhesive between the touchpad and the Bezel, at the
same time, pull the side3 of the Bezel.
3.16：Pull the right upper corner of the Bezel to
separate with the touchpad.
3.17：Dip the cleaning rod with Alcohol into the
adhesive between the touchpad and the Bezel, at the
same time, pull the side4 of the Bezel.
To Next Page
