110W（MS-N0E1）Disassembly Guide
1、COVER ASSY
1.1：Remove the 4 Rubbers, then remove the 4
screws (M2.5*5mm).
Attention: the screw driver torque is 1.5-2.0Kgf-cm
Component P/N Qty
Rubber E2Y-0E10711-Y40 4
Screw E43-1255001-H29 4
1.2：Remove the volume button.
1.3 ： Separate the Cover and Bezel, first
remove the up side, and then remove left
side and right side, last remove the down
side.
UP
LEFT RIGHT
DOWN
To Next Page
