110W（MS-N0E1）Disassembly Guide
2、MB ASSY
2.1：Remove the battery cable.
2.2：Remove the GPS Mylar as pic shows.
2.3：Remove the 2 screws(M2*3mm), then remove
the antenna and GPS card.
Attention: the screw driver torque is 1.2-1.5Kgf-cm
Component P/N Qty
GPS card S5D-0400010-T46 1
Screw E43-1203003-H29 2
