110W（MS-N0E1）Disassembly Guide
2、MB ASSY
2.16：Remove the Motor cable.
2.17：Remove the Motor.
2.18：Separate the Motor and the rubber.
Component P/N Qty
Motor
OS9-N0D1001 1
Rubber
E2Y-0D10511-Y40 1
