Serial ATA Connector: SATA1~8
This connector is a high-speed Serial ATA interface port. Each connector can con-
nect to one Serial ATA device.
SATA4
SATA3
SATA6
SATA2
SATA5
SATA1
Important
1. Please do not fold the Serial ATA cable into 90-degree angle. Otherwise,
data loss may occur during transmission.
2. SATA1~6 controlled by Intel
®
ICH10R/ ICH10, and the ICH10R supports
RAID 0/ 1/ 0+1/ 5 mode.
3. SATA7~8 controlled by JMicron
®
JMB363 and they support RAID 0/ 1
mode.
SATA8
SATA7
