2-14
Hardware Setup
Fan Power Connectors: CPUFAN,SYSFAN1~4
The fan power connectors support system coolng fan wth +12V. When connectng the
wre to the connectors, always note that the red wre s the postve and should be con-
nected to the +12V; the black wre s Ground and should be connected to GND. If the
manboard has a System Hardware Montor chpset on-board, you must use a specally
desgned fan wth speed sensor to take advantage of the CPU fan control.
1
.Ground
2.+12V
3.Sensor
/ N
o U
se
1
.
G
r
o
u
n
d
2
.
+
1
2
V
3
.
S
e
n
s
o
r
4
.
C
o
n
t
r
o
l
CPUFAN
SYSFAN1~4
Important
Please refer to the recommended CPU fans at processor’s o󰘲cal webste or consult
the vendors for proper CPU coolng fan.
CPUFAN support Smart fan control. You can nstall
Control Center utlty that wll
automatcally control the CPUFAN speeds accordng to the actual CPUFAN tem-
peratures.
Fan cooler set wth 3 or 4 pns power connector are both avalable for CPUFAN.
DLED3 Connector: JDLED3
Ths s reserved for connectng the ms future control card.
10.No
Pi
n
14.Contro
l pin
8.Contro
l p
in
12.Contro
l pin
6
.Ground
4.Contro
l pin
2.Contro
l pin
1.5VSB
3.Contro
l pin
5.Contro
l pin
7.Contro
l pin
9
.Ground
11
.
Reserve
d p
in
13.Ground
