MSI P67A-G43 (B3) Series User Manual

2-13
MS-7673
Chapter 2
Connectors
Seral ATA Connector: SATA1~6
Ths connector s a hgh-speed Seral ATA nterface port. Each connector can connect
to one Seral ATA devce.
* The MB layout n ths 󰘰gure s for reference only.
SATA1~2 (6 Gb/s)
supported by Intel
®
P67
SATA3~6 (3 Gb/s)
supported by Intel
®
P67
SATA5
SATA6
SATA4
SATA2
SATA1
SATA3
Important
Please do not fold the Seral ATA cable nto 90-degree angle. Otherwse, data loss may
occur durng transmsson.
Seral Port Connector: JCOM1
Ths connector s a 16550A hgh speed communcaton port that sends/receves 16
bytes FIFOs. You can attach a seral devce.
1
.
D
C
D
3
.
S
O
U
T
1
0
.
N
o
P
i
n
5
.
G
r
o
u
n
d
7
.
R
T
S
9
.
R
I
8
.
C
T
S
6
.
D
S
R
4
.
D
T
R
2
.
S
I
N
