Important
If you do not have any EMI problem, leave the settng at [Dsabled] for optmal system
stablty and performance. But f you are plagued by EMI, select the value of Spread
Spectrum for EMI reducton.
The greater the Spread Spectrum value s, the greater the EMI s reduced, and the
system wll become less stable. For the most sutable Spread Spectrum value, please
consult your local EMI regulaton.
Remember to dsable Spread Spectrum f you are overclockng because even a slght
jtter can ntroduce a temporary boost n clock speed whch may just cause your over
-
clocked processor to lock up.
VDroop Control
Ths tem s used to select the VDroop control mode.
Current CPU Core Voltage/ Current DRAM Voltage
These tems show current CPU Core/ DRAM voltage. Read-only.
PCH 1.05
These tems are used to adjust the voltage of chpset.
Overclockng Proles
Press <Enter> to enter the sub-menu.
Overclockng Prole 1/ 2/ 3/ 4/ 5/ 6
Press <Enter> to enter the sub-menu. In the sub-menu, these tems are used to save
the current settngs, and you can to load the settngs from the stored prole.
OC Retry Count
When overclockng has faled, settng ths tem as [1, 3] wll allow system to reboot
1/ 3 tmes wth the same overclocked conguraton. If overclockng has faled every
tme, the system wll restore the defaults.
CPU Speccatons
Press <Enter> to enter the sub-menu. The submenu shows the nformaton of nstalled
CPU.
CPU Technology Support
Press <Enter> to enter the sub-menu. The sub-menu shows the nstalled CPU tech
-
nologes. Read only.
•
•
•
▶
▶
▶
▶
▶
▶
▶
▶
