MSI P67A-GD53 Series - Advanced Overclocking Settings - Part 2; Voltage and Profile Settings

En-33
Englsh
tRFC
Ths settng determnes the tme RFC takes to read from and wrte to a memory
cell.
tWR
Mnmum tme nterval between end of wrte data burst and the start of a precharge
command. Allows sense ampl󰘰ers to restore data to cells.
tWTR
Mnmum tme nterval between the end of wrte data burst and the start of a col
-
umn-read command. It allows I/O gatng to overdrve sense ampl󰘰ers before read
command starts.
tRRD
Spec󰘰es the actve-to-actve delay of d󰘯erent banks.
tRTP
Tme nterval between a read and a precharge command.
tFAW
Ths tem s used to set the tFAW (four actvate wndow delay) tmng.
tWCL
Ths tem s used to set the tWCL (Wrte CAS Latency) tmng.
tCKE
Ths tem s used to set the tCKE tmng.
Advanced Channel 1/ 2 Tmng Con󰘰guraton
Press <Enter> to enter the sub-menu. And you can set the advanced memory tmng
for each channel.
tRRDR/ tRRDD/ tWWDR/ tWWDD/ tRWDRDD/ tWRDRDD/ tRWSR
These tems s used to set the memory tmngs for memory channel 1/ 2.
VDroop Control
Ths tem s used to select the VDroop control mode.
CPU Vcore/ CPU IO/ DRAM Voltage/ CPU SA/ CPU PLL Voltage/ DDR_VREF_CA_A/
DDR_VREF_CA_B/ DDR_VREF_DA_A/ DDR_VREF_DA_B/ PCH 1.05
These tems are used to adjust the voltage of CPU, Memory and chpset.
Current CPU Vcore/ Current CPU IO/ Current DRAM Voltage/ Current CPU SA
These tems show current CPU Vcore/ CPU IO/ DRAM voltage. Read-only.
Overclockng Pro󰘰le
Press <Enter> to enter the sub-menu.
Overclockng Pro󰘰le 1/ 2/ 3/ 4/ 5/ 6
Press <Enter> to enter the sub-menu. In the sub-menu, these tems are used to save
the current settngs, and you can to load the settngs from the stored pro󰘰le.
OC Retry Count
When overclockng has faled, settng ths tem as [1, 3] wll allow system to reboot
1/ 3 tmes wth the same overclocked con󰘰guraton. If overclockng has faled every
tme, the system wll restore the defaults.
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
