En-3
English
Connectors
Back panel
- 1 PS/2 mouse port
- 1 PS/2 keyboard port
- 1 eSATA port (optional)
- 4 USB 2.0 Ports
- 1 LAN jack
- 6 flexible audio jacks
- 1 COM port
On-Board Pinheaders / connectors
- 1 D-Bracket 2 pinheader
- 2 USB 2.0 pinheaders (4 ports)
- 1 chasis intrusion connector
- 4 SATAII connectors
- 1 SPDIF pinheader
- 1 front audio pinheader
- 1 CD-in connector
Slots
For P6N SLI V2 Series
- 2 PCI Express x16 slots, both running at x8.
- 2 PCI Express x1 slots
- 2 PCI slots (Support 3.3V/ 5V PCI bus Interface)
For P6N Ultra Series
- 2 PCI Express x16 slots, PCI_E2 - running at x16, PCI_E4 -
stopping.
- 2 PCI Express x1 slots
- 2 PCI slots (Support 3.3V/ 5V PCI bus Interface)
Form Factor
- ATX (30.4cm X 24.5cm)
Mounting
- 9 mounting holes
