MSI PRO B760M-E DDR4 User Manual

16
Continued from previous column
Audio
Realtek® ALC897Codec
 7.1-Channel High Definition Audio
LAN 1x Realtek® RTL8111H 1Gbps LAN controller
Power Connectors
 1x 24-pin ATX main power connector
 1x 8-pin +12V power connector
Internal USB
Connectors
 1x USB 3.2 Gen 1 5Gbps connectors (From B760 chipset)
• Supports additional 2 USB 3.2 Gen 1 5Gbps ports
 2x USB 2.0 Type-A connectors (From Hub-GL850G)
• Supports additional 4 USB 2.0 ports
Fan Connectors
 1x 4-pin CPU fan connector
 2x 4-pin system fan connectors
System Connectors
 1x Front panel audio connector
 2x System panel connectors
 1x Chassis intrusion connector
 1x TPM module connector
 1x serial port connector
Jumpers  1x Clear CMOS jumper
LED Features
 1x 4-pin RGB LED connector
 4x EZ Debug LED
Back Panel
Connectors
 1x HDMI™ port
 1x VGA port
 1x PS/2 keyboard/ mouse combo port
 4x USB 2.0 Type-A ports (From B760 chipset)
 2x USB 3.2 Gen 1 5Gbps Type-A ports (From B760 chipset)
 1x LAN (RJ45) port
 3x audio jacks
I/O Controller NUVOTON NCT6687-D Controller Chip
Continued on next column

MSI PRO B760M-E DDR4 Specifications

General

Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium Gold
Supported processor sockets	LGA 1700
Maximum number of SMP processors	1
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	4800, 4600, 4400, 4266, 4200, 4000, 3800, 3733, 3600, 3466, 3400, 3333, 3200, 2933, 2666, 2400, 2133 MHz
Supported memory clock speed (max)	4800 MHz
Wi-Fi	No
Ethernet interface type	Gigabit Ethernet
Number of SATA III connectors	4
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	M.2, SATA III
BIOS type	UEFI AMI
ACPI version	6.4
BIOS memory size	256 Mbit
System Management BIOS (SMBIOS) version	3.5
Parallel processing technology support	-
Audio chip	Realtek ALC897
Component for	PC
Power source type	ATX
Motherboard chipset	Intel B760
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10, Windows 11

Weight and Dimensions

Depth	236.16 mm
Width	200 mm
