MSI PRO B760M-E DDR4 User Manual

15
Specifications
CPU
 Supports 12th/ 13th Gen Intel® Core™ Processors,
Pentium® Gold and Celeron® Processors*
 Processor socket LGA1700
* Please go to www.msi.com to get the newest support status as new processors
are released.
Chipset Intel® B760 Chipset
Memory
 2x DDR4 memory slots, supporting up to 64GB*
 Supports 1R 2133/ 2666/ 3200 MHz (by JEDEC & POR)
• 1DPC 1R Max speed up to 4800+ MHz
• 1DPC 2R Max speed up to 4600+ MHz
 Supports Dual-Channel mode
 Supports non-ECC, un-buffered memory
 Supports Intel® Extreme Memory Profile (XMP)
* Please refer to www.msi.com for more information on compatible memory.
Expansion Slots
 1x PCIe x16 slot (From CPU)
• Supports up to PCIe 4.0 x16
 1x PCIe x1 slot (From B760 chipset)
• Supports up to PCIe 3.0 x1
Onboard Graphics
 1x HDMI™ 1.4 port with HDR, supporting a maximum
resolution of 4K 30Hz*/**
 1x VGA port, supporting a maximum resolution of
2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz*/**
* Available for the processor with integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
SATA Ports
4x SATA 6Gb/s ports* (From B760 chipset)
* SATA_5 will be unavailable when installing M.2 SATA SSD in M2_1 slot.
M.2 SSD Slot
 1x M.2 slot* (Key M) (From CPU)
• Supports up to PCIe 4.0 x4
• Supports 2242/2260/2280 storage devices
* SATA_5 will be unavailable when installing M.2 SATA SSD in M2_1 slot.
RAID
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices
Continued on next column

MSI PRO B760M-E DDR4 Specifications

General

Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium Gold
Supported processor sockets	LGA 1700
Maximum number of SMP processors	1
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	4800, 4600, 4400, 4266, 4200, 4000, 3800, 3733, 3600, 3466, 3400, 3333, 3200, 2933, 2666, 2400, 2133 MHz
Supported memory clock speed (max)	4800 MHz
Wi-Fi	No
Ethernet interface type	Gigabit Ethernet
Number of SATA III connectors	4
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	M.2, SATA III
BIOS type	UEFI AMI
ACPI version	6.4
BIOS memory size	256 Mbit
System Management BIOS (SMBIOS) version	3.5
Parallel processing technology support	-
Audio chip	Realtek ALC897
Component for	PC
Power source type	ATX
Motherboard chipset	Intel B760
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10, Windows 11

Weight and Dimensions

Depth	236.16 mm
Width	200 mm
