MSI PRO Z690-A WIFI DDR4 User Manual

4



 Supports 12th Gen Intel® Core™ Processors
 Processor socket LGA1700
* Please go to msi.com to get the newest support status as
new processors are released.
 Intel®
Z690 chipset

 4x DDR4 memory slots, support up to 128GB*
 Supports 2133/ 2666/ 3200 MHz (by JEDEC & POR)
 Max overclocking frequency:
 1DPC 1R Max speed up to 5200+ MHz
 1DPC 2R Max speed up to 4800+ MHz
 2DPC 1R Max speed up to 4400+ MHz
 2DPC 2R Max speed up to 4000+ MHz
 Supports Dual-Channel mode
 Supports non-ECC, un-buffered memory
 Supports Intel® Extreme Memory Profile (XMP)
*Please refer msi.com for more information on compatible
memory

 3x PCIe x16 slots
 PCI_E1 (From CPU)
 Support PCIe 5.0 x16
 PCI_E3 & PCI_E4 (From Z690 chipset)
 Support PCIe 3.0 x4 & 3.0 x1
 1x PCIe 3.0 x1 slot (Fom Z690 chipset)

Realtek® ALC897 Codec
 7.1-Channel High Definition Audio
  Supports AMD CrossFire™ Technology


 1x HDMI 2.1 with HDR port, supports a maximum resolution
of 4K 60Hz *
/
**
 1x DisplayPort 1.4 port, supports a maximum resolution of
4K 60Hz *
/
**
* Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU
installed.
Continued on next page

MSI PRO Z690-A WIFI DDR4 Specifications

General

Form Factor	atx
Chipset	z690
Chipset Compatibility	intel
Processor Socket	socket lga 1700
Processor Compatibility	intel, intel core i9, intel core i7, intel core i5, intel core i3
RAID	raid 0, raid 1, raid 5
Multi-GPU	crossfire
Memory Type	ddr5
Memory Speeds	6400
SATA Connectors	6x sata 6g
Wireless Standard	ax
Wireless Networking Standard	wi-fi 6e
Wireless Connectivity	bluetooth, wi-fi
USB Ports	3 x usb-c 3.2, 6 x usb-a 3.2, 8 x usb-a 2.0
Audio Ports	1x front audio (jaud)
Audio Channels	8
M.2 Slots	4

Weight and Dimensions

Width	243.84 millimeters
