Right Side View
1. Combo Audio Port
• A port for a headset, microphone, or headset with
microphone.
• The Combo Audio Port supports 4-Pole 3.5mm
headphone jack.
2. USB 3.2 Gen 2 Port
USB 3.2 Gen 2, the SuperSpeed USB 10Gbps, supports high-speed data transfer for
the connected devices, such as storage devices, hard drives, or video cameras.
3. Status LED
Battery Status
• LED turns white when the battery is being charged.
• LED turns white and blinks when the battery is in fast
charging.
• LED turns amber while the battery is in low capacity status.
• LED turns amber and blinks if the battery fails. If the
problem persists, please contact your local authorized
retailer or service center.
• Battery LED goes out when the battery is fully charged or
when the AC/DC adapter is disconnected.
