2-10 2-11
Bottom Side View
1. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air
circulation.
2. Battery Reset Hole (optional)
Whenever the system firmware (EC) is upgraded or the system hangs, please 1)
power off the notebook; 2) remove the AC power; 3) use a straightened paperclip and
insert it to this hole for 10 secs; 4) connect the AC power; 5) power on the notebook.
For models that do not support battery reset by Battery Reset Hole, please refer to
Power Key in Top-open View to execute battery reset.
3. Woofer Speaker
The woofer speaker is to reproduce low-pitched audio frequency.
