5
Getting Started
1
Power Button/ Power LED
Press the power button to turn the system on and off.
The power LED glows when the system is turned on and goes off when
the system is shut down. In terms of power saving, the LED blinks in S3
(Suspend to RAM) mode and goes off in S4 (Suspend to Disk) mode.
2
HMI 2.0
HMI (Human Machine Interface) 2.0 features a touch
panel for easy, smart human-machine interaction and
communication. For detailed instructions, please refer
to the following documentation.
MSI Center:
http://download.msi.com/manual/mb/
MSICENTER.pdf
HMI 2.0:
https://download.msi.com/archive/mnu_exe/
mb/HMI2.pdf
MSI Center
HMI 2.0
3
USB 3.2 Gen 1 Port
This connector is provided for USB peripheral devices. (Speed up to 5
Gbps)
4
Headphone Jack
This connector is provided for headphones or speakers.
5
Microphone Jack
This connector is provided for microphones.
6
USB 3.2 Gen 2 Port (Type-C)
This connector is provided for USB peripheral devices. This connector can
provide up to 5V/3A of power. (Speed up to 10 Gbps)
7
Hard Disk Drive LED
This indicator shows the activity status of the HDD. It flashes when the
system is accessing data on the HDD and remains off when no disk activity
is detected.
8
Line-In Jack
This connector is provided for external audio output devices.
9
Line-Out Jack
This connector is provided for headphones or speakers.
10
Mic-In Jack
This connector is provided for microphones.
