7
Getting Started
18
HDMI™ Connector
Supports 4K@30Hz as specified in HDMI™ 1.4b.
⚠
Important
∙
Graphics specifications may vary depending on the installed CPU.
∙
For processors without integrated graphics, connect your monitor to the
discrete graphics card.
19
PS/2® Keyboard/ Mouse Port
The PS/2® keyboard/ mouse DIN connector for PS/2® keyboard/ mouse.
20
USB 2.0 Port
This connector is provided for USB peripheral devices. (Speed up to 480
Mbps)
⚠
Important
High-speed devices are recommended for USB 3.2 ports whereas low-
speed devices, such as mouse or keyboard, are suggested to be plugged
into the USB 2.0 ports.
21
Kensington Lock Port
This PC provides a Kensington lock port, which allows users to secure
the PC in place with a key or some mechanical PIN device and attached
through a rubberised metal cable. The end of the cable has a small loop
which allows the whole cable to be looped around a permanent object,
such as a heavy table or other similar equipment, thus securing the PC in
place.
22
Ventilator
The ventilator on the enclosure is used for air convection and to prevent
the equipment from overheating. Do not cover the ventilator.
23
Power Jack
Power supplied through this jack supplies power to your system.
24
Power Supply Switch
Switch this switch to I can turn on the power supply. Switch it to 0 to cut off
the power circulation.
25
Zero Fan Button
Push the button to turn Zero Fan ON or OFF.
Zero Fan Description
ON
System
Load
Below 40% The power supply fan stops.
Above 40% The power supply fan starts.
OFF The power supply fan runs constantly.
