2-8 2-9
Introductions
Left Side View
1. Kensington Lock
This notebook provides a Kensington lock hole, which allows users to secure the
notebook in place.
2. Status LED
Battery Status
• LED glows when the battery is being charged.
• LED turns amber while the battery is in low capacity status.
• Continuously blinking if the battery fails. If the problem
persists, please contact your local authorized retailer or
service center.
• Battery LED goes out when the battery is fully charged or
when the AC/DC adapter is disconnected.
3. Combo Audio Port
• A port for a headset, microphone, or headset with
microphone.
• The Combo Audio Port supports 4-Pole 3.5mm
headphone jack.
4. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air
circulation.
To Next Page
