Introductions
Rear Side View
1. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air
circulation.
2. Thunderbolt (Type-C) port
• Thunderbolt™4, optionally supports USB4, PCIe, HDMI, DisplayPort connection;
8K display monitor output; up to 40Gbps transfer rate.
• Supports maximum 5V/3A portable charging power output when AC power is
connected. However, the maximum portable charging power limitation may up to
5V/1.5A while only battery DC power is connected.
3. HDMI Connector
HDMI (High-Definition Multimedia Interface) technology is the industry-leading
interface and de-facto standard connecting high-definition (HD) and ultra high-
definition (UHD) equipment.
4. RJ-45 Connector
The Ethernet connector, with optionally supported transmitting rate of
10/100/1000/2500 megabits per second, is used to connect a LAN cable for network
connection.
5. Power Connector
This connector is to connect the AC/DC adapter and supply power for the notebook.
