Overview of Components
Component Contents
Port Name Port Type Page
BIOS_SW1 Multi-BIOS Switch 46
CPU_FAN1, PUMP_FAN1, SYS_FAN1~4 Fan Connectors 44
CPU_PWR1, ATX_PWR1 Power Connectors 40
CPU Socket LGA2066 29
DIMMA1~D2 DIMM Slots 30
JAUD1 Front Audio Connector 45
JBAT1
Clear CMOS (Reset BIOS)
Jumper
47
JCI1 Chassis Intrusion Connector 45
JFP1, JFP2 Front Panel Connectors 41
JLED1 RGB LED connector 48
JTBT1
Thunderbolt Add-on Card
Connector
44
JTPM1 TPM Module Connector 43
JUSB1~2 USB 2.0 Connectors 43
JUSB3, JUSB4 USB 3.1 Gen1 Connectors 41
JUSB5 USB 3.1 Gen2 Type-C Connector 42
M2_1~2 M.2 Slots (Key M) 37
PCI_E1~6 PCIe Expansion Slots 33
POWER1, RESET1 Power Button, Reset Button 47
SATA1~8 SATA 6Gb/s Connectors 38
U2_1 U.2 Connector 36
VRAID1 Virtual RAID on CPU Connector 40
