X340（MS-1352）Disassemble Guide

2、LOWER CASE ASSY

2.1：Push the Dummy card firstly, then remove it

after it pop up;

Component P/N Qty

Dummy Card E2P-3512611-Y31 1

2.2：Remove the 10 screws (M2*2.5mm);

Attention: the screw driver touque is: 1.5-2.0Kgf-cm

Component P/N Qty

Screw E43-1202506-H29 10
