X340MS-1352Disassemble Guide
3KEYBOARD
3.1Before removing K/B, firstly release the 2
hooks of the middle of the keyboard upside.
3.2Insert the stick below the keyboard
3.3Release the 2 hooks of the two sides of the
keyboard upside, then raise upside of the keyboard
