MSI X79A-GD65 (8D) Series User Manual

1-29
MS-7760
Chapter 1
USB 2.0 Expanson Connectors: JUSB2, JUSB3
Ths connector s desgned for connectng hgh-speed USB perpherals such as USB
HDDs, dgtal cameras, MP3 players, prnters, modems, and many others.
BATT
+
115V
10. NC
8
.Gr ound
6.U SB1
+
4.U SB1
-
2.V C
C
1.V C
C
3.U SB0
-
5.U SB0
+
7
.Gr ound
9.N o
Pi
n
* The MB layout n ths 󰘰gure s for reference only.
USB 2.0 Bracket (optonal)
The JUSB3 (red mark) connector supports MSI’s new SuperCharger technology
whch provdes qucker USB chargng of your cellular phone or other USB-powered
devces. To enable ths feature, please nstall the MSI SuperCharger applcaton on
your computer. When the SuperCharger applcaton s turned on, the JUSB3 connector
wll convert data channels to extra power channels to quckly charge your connected
devce. Please note that when the SuperCharger applcaton s turned on, data
transmsson and synchronzaton over the JUSB3 connector wll not functon. To enable
the JUSB3 connector to functon as a normal USB 2.0 connector, please turn o󰘯 the
SuperCharger applcaton. When the computer s n stand-by or hbernaton mode (S3/
S4/ S5) SuperCharger mode wll automatcally be enabled.
Important
Note that the VCC and GND pns must be connected correctly to avod possble
damage.
Please only connect one devce per USB port to ensure stable chargng.
SuperCharger Technology s only avalable on select MSI manboard models. Please
refer to the MSI webste to check f your manboard has SuperCharger technology.
For Pad, JUSB3
(red mark) can stll charge Pad n S3, S4, S5 state.
We recommend that don’t dsconnect the devce when you charge t n S1 state.
•
•
•
•
•
