MSI Z170A TOMAHAWK AC

15
Specifications
Specifications
CPU
Supports 6th Gen Intel
®
Core
™
i3/i5/i7 processors, and Intel
®
Pentium
®
and Celeron
®
processors for Socket LGA1151
Chipset Intel
®
Z170/ B150 Chipset (optional)
Memory
y 4x DDR4 memory slots, support up to 64GB
 Supports DDR4 3600(OC)/ 3200(OC)/ 3000(OC)/2800(OC)/
2600(OC)/ 2400(OC)/ 2133 MHz*
y Dual channel memory architecture
y Supports ECC, un-buffered memory*
y Supports Intel
®
Extreme Memory Profile (XMP)
* Only Z170 supports overclocking (OC) frequency.
** Supports ECC UDIMM 1Rx8/2Rx8 memory (non-ECC mode)
* *Supports non-ECC UDIMM 1Rx8/2Rx8/1Rx16 memory
Expansion Slots
y 2x PCIe 3.0 x16 slots (support x16/x4 modes)
y 3x PCIe 3.0 x1 slots
y 2x PCI slots*
y 1x M.2 Wi-Fi module slot (Key E)
* No support PCI wake-up on S3, S4 & S5
Onboard Graphics
y 1x HDMI
™
port, supports a maximum resolution of
4096x2160@24Hz, 2560x1600@60Hz
y 1x DVI-D port, supports a maximum resolution of
1920x1200@60Hz
Multi-GPU y Supports 2-Way AMD
®
CrossFire
™
Technology
Storage
Intel
®
Z170/ B150 Chipset
y 6x SATA 6Gb/s ports*
y 1x M.2 slot (Key M)
 Supports PCIe 3.0 x4 and SATA 6Gb/s standards, 4.2cm/
6cm/ 8cm length M.2 SSD cards (optional)**
 Supports PCIe 3.0 x4 NVMe Mini-SAS SSD with Turbo U.2
Host Card (optional)***
y Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices (optional)
y Supports Intel
®
Smart Response Technology for Intel
Core
™
processors (optional)
* SATA5~6 ports will be unavailable when installing the M.2 module in M.2
(M2_1) slot.
** Only support M.2 SATA interface for B150.
*** The Turbo U.2 Host Card is not included, please purchase separately.
Continued on next page
