MSI Z170A TOMAHAWK User Manual

16
Specifications
Continued from previous page
USB
y ASMedia
®
ASM1142 Chipset (optional)
 2x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports on the
back panel (optional)
y Intel
®
Z170/ B150 Chipset
 6x USB 3.1 Gen1 (SuperSpeed USB) ports (2 ports on the
back panel, 4 ports available through the internal USB
3.1 Gen 1 connectors)
 4x or 6x USB 2.0 (High-speed USB) ports (2 or 4 ports
on the back panel, 2 ports available through the internal
USB 2.0 connectors) (optional)
Audio
y Realtek
®
ALC892 Codec
y 7.1-Channel High Definition Audio
y Supports S/PDIF output
LAN 1x Realtek
®
RTL8111H Gigabit LAN controller
WLAN & Bluetooth
®
(optional)
y Wi-Fi/ Bluetooth
®
expansion module with Intel
®
Dual Band
Wireless-AC 8260 chip (optional)
 Supports Wi-Fi 802.11 a/b/g/n/ac, dual band (2.4GHz,
5GHz) up to 867 Mbps speed.
 Supports Dual Mode Bluetooth
®
2.1, 2.1+EDR, 3.0, 4.0,
BLE, 4.2
Back Panel
Connectors
y 1x PS/2 keyboard/ mouse port
y 4x or 2x USB 2.0 ports (optional)
y 2x USB 3.1 Gen2 ports (optional)
y 1x DVI-D port
y 1x HDMI
™
port
y 1x Clear CMOS button
y 1x LAN (RJ45) port
y 2x USB 3.1 Gen1 ports
y 1x Optical S/PDIF OUT connector
y 5x OFC audio jacks
Continued on next page

MSI Z170A TOMAHAWK Specifications

General

Chipset	Intel Z170
Socket	LGA 1151
Form Factor	ATX
Memory Slots	4
Maximum Memory	64 GB
PCIe x16 Slots	2
PCIe x1 Slots	3
SATA Ports	6
M.2 Slots	1
USB 3.1 Gen1 Ports	6
USB 2.0 Ports	6
Audio	Realtek ALC892
Memory Speed	2133 MHz
RAID Support	Yes (0, 1, 5, 10)
Multi-GPU Support	AMD CrossFire
USB 3.1 Gen2 Ports	2 (1 Type-A, 1 Type-C)
