Page #15 background imageLoading...
Page #15 background image
15
Specifications
Specifications
CPU
Supports 6th Gen Intel
®
Core
i3/i5/i7 processors, and Intel
®
Pentium
®
and Celeron
®
processors for Socket LGA1151
Chipset Intel
®
Z170/ B150 Chipset (optional)
Memory
y 4x DDR4 memory slots, support up to 64GB
Supports DDR4 3600(OC)/ 3200(OC)/ 3000(OC)/2800(OC)/
2600(OC)/ 2400(OC)/ 2133 MHz*
y Dual channel memory architecture
y Supports ECC, un-buffered memory*
y Supports Intel
®
Extreme Memory Profile (XMP)
* Only Z170 supports overclocking (OC) frequency.
** Supports ECC UDIMM 1Rx8/2Rx8 memory (non-ECC mode)
* *Supports non-ECC UDIMM 1Rx8/2Rx8/1Rx16 memory
Expansion Slots
y 2x PCIe 3.0 x16 slots (support x16/x4 modes)
y 3x PCIe 3.0 x1 slots
y 2x PCI slots*
y 1x M.2 Wi-Fi module slot (Key E)
* No support PCI wake-up on S3, S4 & S5
Onboard Graphics
y 1x HDMI
port, supports a maximum resolution of
4096x2160@24Hz, 2560x1600@60Hz
y 1x DVI-D port, supports a maximum resolution of
1920x1200@60Hz
Multi-GPU y Supports 2-Way AMD
®
CrossFire
Technology
Storage
Intel
®
Z170/ B150 Chipset
y 6x SATA 6Gb/s ports*
y 1x M.2 slot (Key M)
Supports PCIe 3.0 x4 and SATA 6Gb/s standards, 4.2cm/
6cm/ 8cm length M.2 SSD cards (optional)**
Supports PCIe 3.0 x4 NVMe Mini-SAS SSD with Turbo U.2
Host Card (optional)***
y Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices (optional)
y Supports Intel
®
Smart Response Technology for Intel
Core
processors (optional)
* SATA5~6 ports will be unavailable when installing the M.2 module in M.2
(M2_1) slot.
** Only support M.2 SATA interface for B150.
*** The Turbo U.2 Host Card is not included, please purchase separately.
Continued on next page

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the MSI Z170A TOMAHAWK and is the answer not in the manual?

MSI Z170A TOMAHAWK Specifications

General IconGeneral
ChipsetIntel Z170
SocketLGA 1151
Form FactorATX
Memory Slots4
Maximum Memory64 GB
PCIe x16 Slots2
PCIe x1 Slots3
SATA Ports6
M.2 Slots1
USB 3.1 Gen1 Ports6
USB 2.0 Ports6
AudioRealtek ALC892
Memory Speed2133 MHz
RAID SupportYes (0, 1, 5, 10)
Multi-GPU SupportAMD CrossFire
USB 3.1 Gen2 Ports2 (1 Type-A, 1 Type-C)
