MSI Z68S-G43 G3 Series

En-3
Englsh
If you need to purchase accessores and request the part numbers, you could search
the product web page and 󰘰nd detals on our web address http://www.ms.com/ndex.
php
Connectors
Back panel
1x PS/2 keyboard port
1x PS/2 mouse port
2x USB 3.0 ports & 4x USB 2.0 ports (Z68A-G43 (G3))
6x USB 2.0 ports (Z68S-G43 (G3))
1x LAN port
1x VGA port **
1x DVI-D port **
6x audo ports (Z68A-G43 (G3))
3x audo ports (Z68S-G43 (G3))***
**(The VGA and DVI-D ports only work wth the CPU’s Integrated Graphcs
Processor)
***(To reach the 8-channel sound e󰘯ect, the 7th and 8th channels must be
outputted from front panel.)
On-Board
4x USB 2.0 connectors
1x Chasss Intruson connector
1x S/PDIF-Out connector
1x Front Panel Audo connector
1x TPM Module connector (optonal)
1x Parallel connector
1x Seral connector
Slots
1x PCIe 3.0 x16 slot (PCI_E2)
1x PCIe 2.0 x16 slot (PCI_E4, t supports up to x4 speed)
2x PCIe 2.0 x1 slots
Only 1x PCIe x1 (PCI_E1 or PCI_E3) slot can be used at a tme due to chpset
bandwdth lmtaton. Usng the PCI_E1 slot s recommended.
3x PCI slots
Form Factor
ATX (22.0 cm X 30.5 cm)
Mountng Screw Holes
6x mountng holes
■
-
-
-
-
-
-
-
-
-
■
-
-
-
-
-
-
-
■
■
■
-
■
■
■
