MSI Z68S-G43 G3 Series

En-6
MS-7750 Manboard
Back Panel Quck Gude
Mouse/Keyboard
The standard PS/2
®
mouse/keyboard DIN connector s for a PS/2
®
mouse/keyboard.
USB 2.0 Port
The USB 2.0 port s for attachng USB 2.0 devces such as keyboard, mouse, or other
USB 2.0-compatble devces.
USB 3.0 Port (optonal)
USB 3.0 port s backward-compatble wth USB 2.0 devces. It supports data transfer
rate up to 5 Gbt/s (SuperSpeed).
Important
In order to use USB 3.0 devces, you must connect to a USB 3.0 port. If a USB cable s
used, t must be USB 3.0 complant.
▶
▶
▶
Keyboard
Lne-In
Lne-Out
Mc
RS-Out
CS-Out
SS-Out
USB 2.0 PortUSB 2.0 Port
USB 3.0 Port
LAN
DVI-D Port
Mouse
VGA Port
Keyboard
Lne-In
Lne-Out
Mc
USB 2.0 PortUSB 2.0 Port
USB 2.0 Port
LAN
DVI-D Port
Mouse
VGA Port
Z68A-G43 (G3)
Z68S-G43 (G3)
