Chapter 3
3-29 BIOS Setup
Please follow the description below to set the temperatures and fan speeds.
a
b
c
d
e
f
a - Selects a fan you want to specify the speed.
b - Checks this item to activate the following items for changing default values.
c - Slides the Min and Max tabs to set the minimum and maximum
temperatures.
d - Slides the arrow symbol to set the minimum fan speed in percentage.
e - Slides the arrow symbol to set the maximum fan speed in percentage.
f - Click the "Default" button to restore the default values. Or click the
"Cancel" button to abandon all changes and restore to the previous values.
Important
The minimum values of temperature and speed can not be set larger then the
maximum values.
Voltage display
Shows the current voltages of CPU, system and memory.
■
■
■
■
■
■
▶
