MSV MSAT G2 - USER INTERFACE (UI) OVERVIEW

6 User Guide
USER INTERFACE (UI)
OVERVIEW
Soft Keys
Function changes
based upon display
text above key
E
nd Ke
y
Ends calls and
provides quick exit
from menus
Microphone
L
oudspeaker
- High volume
speaker in
dispatch mode
- Earpiece in
telephone mode
Power Ke
y
Switches
radio on/off
P1 Ke
y
Emergency
Dispatch Radio
call
PTT Ke
y
Push to Talk
Send Ke
y
Initiates calls
Alphanumeric
Keypad
Headset Jack
Scroll Keys
Scrolls through lists
and menus, Adjusts
volume
