Weight
HUGHES 2100 TU = 0.8 lbs
DT-200 Handset = 0.6 lbs
SPAC-AS-MSV220 Antenna = 4.6 lbs
SPAC-AS-MSV320 Antenna = 10.3 lbs
Dimensions
HUGHES 2100 TU = (W) 6.5” x (H) 1.1” x (D) 5.6”
DT-200 Handset = (W) 2.9” x (H) 1.4” x (D) 6.8”
SPAC-AS-MSV220 Antenna = (Diameter) 9.8” x
(Height) 3.9”
SPAC-AS-MSV320 Antenna = (Diameter) 11” x (Height)
11”
Power
Input voltage: 11.5 to 15.6 VDC
Input current: 3 Amps max.
Fuses
Power cable assembly 3004028-0001
Battery (red wire): 5 Amp / 250 Volt
Horn Alert (blue wire): 0.25 Amp / 250 Volt
CAUTION: For continued protection against risk of
fire, replace only with same type and rating of fuse
Humidity
98% at 100.4°F (38°C)
Operating
Temperature
Antenna = -22°F(-30°C) to +109°F(+43°C)
TU = -22°F(-30°C) to +131°F(+55°C)
Dust
In Accordance with SAE J1455 section 4.7
Rain
Antenna = Precipitation rate of 2” /hour
C-Comm, 1715 N. 122nd Street, Seattle WA, 98133 - 206.783.0616
