The original operation manual is in German. Other
language versions are translations from German.
USER MANUAL
SAFETY INSTRUCTIONS
General safety information for the use of electrical devices:
compliance with the safety instructions when using this
device. Please read the instructions carefully and make sure
that you have understood them well. Keep the manual near
the equipment to be able to read it at any time. Always use
current sources that are connected to the ground and
provide the necessary voltage (indicated on the label
on the device). If you have any doubts, let an electrician
check if your outlet is properly grounded. Never use
a damaged power cable. Do not open the unit in damp or
wet environments, or if your hands or body are damp or
wet. Protect the unit from solar radiation. Use the device in
a protected location to avoid damaging the equipment or
endangering others. Make sure the device is able to cool
and avoid placing it too close to other devices that produce
heat. Before cleaning, disconnect it from the power source.
Use a soft damp cloth for cleaning. Avoid using detergents
and make sure that no liquid enters the unit. No internal
element of this device needs to be maintained by the user.
Opening the device without our approval leads to a loss
of warranty!
SAFETY GUIDELINES
1 Please carefully read and understand these
instructions before operating the device! Please
observe the safety guidelines carefully in order to
prevent damages through improper use!
2. Please keep this manual available for future
reference. If this device is passed on to third parties,
the manual must be passed on with it.
3. Only use this device indoors and for its intended use.
from improper use or incorrect operation.
voltage type and current comply with the indicated
data on the type plate.
6. This device is not intended to be used by persons
(including children) with limited physical, sensory
or mental aptitudes or with a lack of experience
and/or knowledge, unless they are supervised by
a person responsible for their safety or have received
instruction from this person as to how the device is
used.
7. ELECTRIC SHOCK HAZARD! Do not attempt to repair
the unit yourself. In case of device failure, repairs
The operation manual must be read carefully.
Never dispose of electrical equipment together
with household waste.
Attention! Risk of electric shock!
serious injury or cause death.
PLEASE NOTE! Drawings in this manual are for
illustration purposes only and in some details they
8. Please check the main plug and power cable
regularly. If the power cable for this device is
damaged, it has to be replaced by the manufacturer
order to prevent hazards.
9. Prevent damages to the power cable by avoiding
squeezing or bending it or rubbing it on sharp
edges. Also keep the power cable away from hot
10. ATTENTION! DANGER TO LIFE! While cleaning, never
immerse the device in water or other liquids.
11. Under no circumstances should the housing be
opened.
12. It is forbidden to use the device if damaged or
defective.
TECHNICAL DATA
Product name Submersible pump
Model MSW
-SPP
44
-075
MSW
-SPP
44
-037
MSW
-SPP
32
-075
MSW
-SPP
48
-110
MSW
-SPP
48
-220
Voltage [V~]/
Frequency
[Hz]
230/50
Rated power
[kW/HP]
0,75/
1
0,37/
0,5
0,75/
1
1,1/
1,5
2,2/
3
Rated Current
[A]
5 3 5 6 14
Protection
class
I
IP protection
class
IP68
Insulation
class
B
Working
mode
S1
Motor rota-
tional speed
[rpm]
2850
Number of
stages
(impellers)
10 6 24 8 14
Borewell di-
ameter [mm]
95 95 75 95 95
Water con-
nector stub
diameter
1,25’’ 1,25’’ 1,25’’ 2’’ 2’’
Max. head
lift [m]
72 43 85 54 96
Max. water
3
/h]
6 6 3,8 10,8 10,8
Max. sand
content in
water [%]
0,25
Pumped
water max.
temp. [°C]
35
Max. number
of starts/h
50
Length of
power cable
[m]
20 ± 1
Dimensions
[mm]
φ90
x870
φ95
x725
φ75
x1290
φ95
x920
φ95
x1362
Weight [kg] 16,9 10 15,4 16 21,9
Product
name
Submersible pump
Model MSW
-SPP
32
-055
MSW
-SPP
44
-055
MSW
-SPP
32
-037
MSW
-SPP
32
-025
MSW
-SPP
43
-075
Voltage [V~]/
Frequency
[Hz]
230/50
Rated power
[kW/HP]
0,55/
0,75
0,55/
0,75
0,37/
0,5
0,25/
0,33
0,75/
1
Rated
Current [A]
4 4 3 2,5 5
Protection
class
I
IP protection
class
IP68
Insulation
class
B
Working
mode
S1
Motor rota-
tional speed
[rpm]
2850
Number of
stages
(impellers)
17 8 11 8 12
Borewell
diameter
[mm]
75 95 75 75 95
Water con-
nector stub
diameter
1,25’’ 1,25’’ 1,25’’ 1,25’’ 1,25’’
Max. head
lift [m]
60 58 39 28 91
Max. water
3
/h]
3,8 6 3,8 3,8 4,8
Max. sand
content in
water [%]
0,25
Pumped
water max.
temp. [°C]
35
Max. number
of starts/h
50
Length of
power cable
[m]
20 ± 1
Dimensions
[mm]
φ75
x1035
φ95
x792
φ75
x841
φ75
x711
φ95
x893
Weight [kg] 12,7 12,8 10 9,5 16,5
MSW
-SPP
44
-075
Head lift [m] 72 69 67 65 62 58
water
m
3
/h 0 0,6 1,2 1,8 2,4 3,0
l/
min
0 10 20 30 40 50
MSW
-SPP
44
-075
Head lift [m] 53 46 37 27 16
water
m
3
/h 3,6 4,2 4,8 5,4 6,0
l/
min
60 70 80 90 100
MSW
-SPP
44
-037
Head lift [m] 43 42 40 39 37 35
water
m
3
/h 0 0,6 1,2 1,8 2,4 3,0
l/
min
0 10 20 30 40 50
MSW
-SPP
44
-037
Head lift [m] 32 27 22 16 9
water
m
3
/h 3,6 4,2 4,8 5,4 6,0
l/
min
60 70 80 90 100
MSW
-SPP
32
-075
Head lift [m] 85 82 79 74 70
water
m
3
/h 0 0,5 1,0 1,5 1,8
l/
min
0 8 17 25 30
MSW
-SPP
32
-075
Head lift [m] 65 52 33 3
water
m
3
/h 2,0 2,5 3,0 3,8
l/
min
33 42 50 63
USER MANUAL
9
Rev. 09.02.2018
8
Rev. 09.02.2018
MSW
-SPP
48
-110
Head lift [m] 54 52 51 48 45
water
m
3
/h 0 1,2 2,4 3,6 4,8
l/
min
0 20 40 60 80
MSW
-SPP
48
-110
Head lift [m] 43 37 32 22 12
water
m
3
/h 6,0 7,2 8,4 9,6 10,8
l/
min
100 120 140 160 180
