User interface elements
1 Holder
2 Position locker
3 O-ring
4 Display
5 Back cover
6 Charge plug
Performance characteristics
• Working voltage: 4-11 V
• Motor power: 6 W
• Maximum needle stroke: 3.8 mm
• Weight with battery 18650: 198 g
• Weight with battery 18350: 179 g
• Weight without battery: 149 g
• Type of charging connector: USB Type-C
• Dimensions: 144x31x31mm
• Operating time at 7 volts with 18650 battery: 12-16 hours
• Operating time at 7 volts with battery 18350: 4-6 hours
• Charging time from the connector with battery 18650: 3 h
• Charging time from the connector with the battery 18350: 1.2 h
• Charging time from charger with battery 18650: 1.5 h
• Charging time from charger with battery 18350: 0.8 h
