10
Installation/removal
Sprocket pattern
CS-M5100-11
Lock ring
Sprocket spacer
< 11-51T > < 11-42T >
Lock ring
Sprocket spacer
11-51T 11-42T
Number of teeth Mark Number of teeth Mark
51,
45,
39,
33,
28
51C,
45G,
39C,
33B,
28G
42,
37,
32,
28,
24
42B,
11S 37A,
11S 32B,
11S 28D,
11S 24D
24 24T bv 21 11S 21H
21 21L 19 11S 19H
18 18G 17 11S 17E
15 15T bj bk bv 15 11S 15C
13 13C 11S 13 11S 13C
11 11B 11S 11 11S 11B
