Contents of Carton
3
6
Before beginning installation, remove all parts from the carton to make sure everything is present. Carton contents are listed below
and shown in Fig. 3-1. The four hardware packs included in this kit are detailed on this and the following page.
• Two Adhesive Foam Strips
• Grass Catcher Cover
• Chute Tube Extension
• Flexible Tube Extension
• Upper Chute Tube
• Two Grass Bag Assemblies
• Bag Support Assembly
• Hinge Cover Pin
• Upright Support
• Chute Discharge Bracket
• Hitch Bracket Kit (5 Pcs.: 2 side & 1 cross mount, 2 wt. mounts)
• Upper Chute Support
• Discharge Chute Elbow
• Weight Bar
• Mounting Bracket Kit (Not needed for this installation)
• Four Hardware Packs (Detailed below and on the next page)
Hardware Pack
689-00341
These mounting brackets not
needed for this installation
Figure 3-1
