MTD 24A-020D000 - Page 15

15
Model 24A-020D000
Ref.
No.
Part No. Part Description
1. 725-1700 Switch Cover
2. 725-3166 Safety Switch
3. 710-0224 Hex Washer Screw #10-16 x.50
4. 629-0920 Wire Harness
5. 710-0604A Hex Washer Screw 5/16-18 x.625
6. 714-0104 Cotter Pin
7. 736-0264 Flat Washer.330 ID x.630 OD
8. 732-0962 Compression Spring
9. 781-0778A Mounting Bracket
10. 747-1153 Lock Rod
11. 710-3008 Hex Cap Screw 5/16-18 x.75
12. 681-0122 Chipper Chute Assembly
13. 726-0454 U-Clip Lock Nut 5/16-18
14. 736-0607 External Lock Washer 5/16
15. 710-0502A Hex Washer Screw 3/8-16 x 1.25
16. 710-0969 Screw #12-16 x 1.0
17. 710-3195 Hex Cap Screw 5/16-18 x 4.5
18. 710-3025 Hex Cap Screw 5/16-18 x.625
19. 710-0604A Hex Washer Screw 5/16-18 x.625
20. 781-1085 Upper Housing
21. 710-1054 Hex Screw 5/16-24 x 1.0
22. 781-0490 Chipper Blade
23. 736-0119 Lock Washer 5/16
24. 712-0411 Hex Lock Nut 5/16-24
25. 681-0152 Impeller Assembly
26. 719-0329 Flail Blade
27. 781-0735 Pin Clip
28. 711-1401 Clevis Pin
29. 715-0166 Spiral Pin
30. 736-0247 Flat Washer.375 ID x 1.25 OD
31. 736-0217 Lock Washer 3/8
32. 710-0818 Hex Cap Screw 3/8-24 x 2.0
33. 681-0154 Screen Assembly
34. 710-3038 Hex Cap Screw 5/16-18 x.875
35. 781-0721A Lower Housing
36. 712-3004A Lock Nut 5/16-18
37. 731-2265 Nozzle Cover
38. 712-0158 Lock Nut 5/16-18
39. 731-1613 Safety Switch Cover
Ref.
No.
Part No. Part Description
