MTD 24A-020D000 - Page 17

17
Model 24A-020D000
Ref.
No.
Part No. Part Description
1. 749-1423 Upper Handle
2. 720-0314 Handle Knob 5/16-18
3. 710-1174 Carriage Bolt
4. 749-0907B Lower Handle
5. 664-0090 Bag Assembly
6. 711-1293 Studs
7. 712-0397 Wing Nut 1/4-20
8. 710-0703 Carriage Screw 1/4-20 x.75
9. 726-0453 Lock U-Clip Nut 3/8-16
10. 781-0777 Rear Wheel Support Brace
11. 712-3004A Flange Lock Nut 5/16-18
12. 714-0104 Cotter Pin
13. 681-0155 Handle Bracket Ass’y LH
681-0156 Hndle Brkt Ass’y RH (Not Shown)
14. 710-3025 Hex Cap Screw 5/16-18 x.625
15. 736-0105 Bell Washer.401 ID x.870 OD
16. 734-1987 Wheel 8 x 8.1
17. 738-1015 Shoulder Screw 3/8-16
18. 781-0725A Front Wheel Support Brace
19. 781-0785 Height Adjustment Bracket
20. 738-1185 Stud 5/16-18 .56 x .75
21. 741-0751 Height Adjustment Bearing
22. 682-0113 Pivot Arm Assembly
23. 720-0426 Height Adjustment Knob
24. 732-1026 Spring Lever
25. 736-0741 Bell Washer .760 ID x .25OD
26. 738-1173 Shoulder Screw .750 ID x .625 OD
27. 712-0431 Flange Lock Nut 3/8-16
28. 736-0314 Thrust Washer .375 ID x .70 OD
29. 736-0232 Wave Washer .531 ID x .781 OD
30. OEM-290-012 Blower Chute Ass’y (If Equipped)
31. 764-0507 Bag
32. 631-0083 Chute Assembly
