MTD 401 Series User Manual

19
Ref.
No.
Part No. Part Description
1. 721-0378 Shaft Seal 1.0 Dia
2. 712-0378 Hex Nut 7/16-20
3. 736-0407 Bell Washer.45 ID x 1.0 OD
4. 721-0379 Shaft Seal.75 Dia
5. 716-0865 Snap Ring.50 Dia
6. 686-0038 Gear Case Assembly - RH Half
7. 618-0245B Shift Assembly
9. 713-0233 Chain - #41 1/2” Pitch x 30 Links
10. 750-0570 Space 1.0 ID x 2.0 OD
11. 736-0163 Thrust Washer 1.03 ID x 1.62 OD
12. 750-0936 Spacer.635 ID x 1.0 OD
13. 736-0518 Thrust Washer.445 ID x 1.92 OD
14. 617-0004 Idler Gear Assembly
15. 736-0351 Flat Washer.760 ID x 1.50 OD
16. 750-0938 Spacer.735 ID x.886 OD
17. 717-1458 Spur Gear 46T
19. 611-0021 Tine Shaft Assembly 18T
20. 713-0226 Chain - #50 5/8” Pitch x 52 Links
21. 738-0885 Jack Shaft 5/8 Dia. X. 2.06 Lg
22. 750-0935 Spacer.635 ID x 1.0 OD
23. 611-04073 Wheel Shaft Assembly
24. 686-0039 Gear Case Assembly - LH Half
25. 710-0896 Hex Washer Screw 1/4-14 x.625
26. 726-0331 Plug
27. 741-0563 Ball Bearing w/Snap Ring
28. 712-3067 Hex Patch Lock Nut 7/16-20
29. 786-0086 Reinforcement Bracket
30. 721-0295 Chain Case Gasket
31. 710-0258 Hex Cap Screw 1/4-20 x.625
32. 736-0329 Lock Washer 1/4
33. 736-0512 Flat Washer.281 ID x.875 OD
34. 741-0124 Ball Bearing
35. 736-0541 Flat Washer
36. 717-1451A Spur Gear 16T
37. 713-0435 Sprocket 11T #41 Chain
38. 736-0265 Flat Washer.88 ID x 1.50 OD
39. 716-0235 Retainer Ring
40. 718-0237 Clutch Key
41. 711-1087 Drive Shaft
42. 732-0863 Compression Spring
43. 741-0862 Detent Ball
44. 718-0234 Clutch Collar
45. 717-1409 Spur Gear 17T
46. 736-0442 Flat Washer.69 ID x 1.06 OD
47. 732-0614 Wire Ring
48. 736-0518 Thrust Washer.445 ID x 1.9 OD
49. 611-0016 Intermediate Gear Assembly
50. 738-0884 Jack Shaft
51. 736-0336 Flat Washer.625 ID x 1.0 OD
52. 750-0931 Spacer.635 ID x.86 OD
53. 617-0003 Tine Drive Assembly
— 686-04073 Complete Gear Case Assembly
Ref.
No.
Part No. Part Description
Model Series 410
