MTD 608 - Page 47

47
Deck: 46-inch
Ref.
No.
Part No. Description
1 618-04137 Pulley-Spindle Assembly
2 683-0254 Deck Hanger Bracket Assembly
3 683-04104 Deck Assembly
4 710-0347 Hex Bolt 3/8-16 x 1.75
5 710-0514 Hex Bolt 3/8-16 x 1.0
6 710-0528 Hex Bolt 5/16-18 x 1.25
7 710-0599 TT Screw 1/4-20 x 0.5
8 710-0751 Hex Bolt 1/4-20 x 0.620
9 710-1260A LD Screw 5/16-18 x 0.75
10 711-04069 Grasscatcher Pin
11 712-0324 Lock Nut 1/4-20
12 712-0417A Flange Nut
13 712-0431 Flanged Lock Nut 3/8-16
14 712-0641 Hex Nut M16
15 712-3006 Hex Nut
16 712-3083 Hex Lock Nut 1/2-13
17 714-0111 Cotter Pin
18 717-04074 Gear: Deck Adjustment
19 726-0233 Push Nut
20 732-0306A Compression Spring
21 732-0594A Extension Spring
22 734-0973 Deck Wheel
23 736-0119 Lock Washer
24 736-0270 Bell Washer
25 736-0760 Lock Washer
26 737-04003B Nozzle (if equipped)
27 737-3007 Grease
28 738-0372B Shoulder Spacer
29 738-0373 Shoulder Screw 3/8-16 x 1.5
30 742-0611A Blade 16.28 Lg.: Three-in-One
31 742-0612A Blade 14.88 Lg.: Three-in-One
32 747-1116 Deck Release Handle
33 747-1130B Deck Rod: Front Adjustment
34 754-04033 V Belt
35 756-1229 Idler Pulley
36 771-11725A Danger Tag (not shown)
37 783-0141 Deck Skirt: Center
38 783-0142 Deck Skirt RH
39 783-0805C Belt Cover
40 783-1025 Chute Stop (not shown)
41 783-1348A Belt Cover
42 783-1421 Idler Bracket
43 711-0792 Hinge Pin
44 732-0602A Compression Spring
45 703-1693A Mounting Bracket
46 731-1031C Deflector: Discharge Chute
47 726-0106 Speed Nut
48
731-1636 Mulch Plug
49
710-0578 Screw 1/4-20 x 1.5
Ref.
No.
Part No. Description
